Heavy Duty High Performance Double Roller CNC Metal Spinning Machine
Heavy Duty High Performance Double Roller CNC Metal Spinning Machine
Heavy Duty High Performance Double Roller CNC Metal Spinning Machine
Heavy Duty High Performance Double Roller CNC Metal Spinning Machine
Heavy Duty High Performance Double Roller CNC Metal Spinning Machine
Heavy Duty High Performance Double Roller CNC Metal Spinning Machine
Heavy Duty High Performance Double Roller CNC Metal Spinning Machine

Heavy Duty High Performance Double Roller CNC Metal Spinning Machine

Model NO.
WLH-DRS1550
Quantity:

Parameter

WLH-DRS650

WLH-DRS850

WLH-DRS1050

WLH-DRS1250

WLH-DRS1550

WLH-DRS2050

WLH-DRS2550

WLH-DRS3550

Max. Diameter of Material

650mm

850mm

1050mm

1250mm

1550mm

2050mm

2550mm

3550mm

Main Motor Power

15kw servo

18.5kw servo

22kw servo

22kw servo

35kw servo

55kw servo

75kw servo

100kw servo

X Travel

650mm

800mm

610mm

680mm

500mm

700mm

800mm

980mm

Z Travel

450mm

700mm

780mm

750mm

1000mm

1200mm

1280mm

1480mm

Tailstock Force

20kn

20kn

30kn

45kn

50kn

110kn

120kn

150kn

Travel of Taistock

500mm

500mm

580mm

800mm

1000mm

1100mm

1200mm

1200mm

Amount of Tools

6+6

6+6

6+6

6+6

8/optional

8/optional

8/optional

8/optional

Thickness of Work Piece (Al, Cu)

0.5-5mm

0.5-5mm

0.5-5mm

0.5-4.5mm

0.5-4.5mm

1-8mm

1-8mm

1-10mm

Thickness of Work Piece (C.S)

0.5-3mm

0.5-3.5mm

0.5-4mm

0.5-4mm

0.5-4mm

1-6mm

1-6mm

1-8mm

Thickness of Work Piece (SS)

0.5-2mm

0.5-2mm

0.5-3mm

0.5-2mm

0.5-3mm

1-4mm

1-4mm

1-6mm

WLH-D series CNC Metal Spinning Machine(Double Roller) is especially developed to spin lamps, lamps, art wares, kitchenwares and auto fittings. It has many patents issued by the State Intellectual Property Office. This machine is practical, professional and strong. It has high production efficiency and can complete horn, bucket, cone type, parabolic products. It can also process threading, trimming, flanging and rolling at the same machine tool. The machine can spin many materials such as carbon steel, stainless steel, aluminum and copper etc. It has solved the traditional problems such as lack of skilled workers. With advanced digital control, it is easy to operate. The machine can improve the production efficiency, machining accuracy and saving the cost of human resources. It is the ideal processing machine for light, automobile, military, mechanic and other manufacturing industries.
